Glyph Technologies Thunderbolt 3 Dock

The Thunderbolt 3 Dock from Glyph is an excellent solution for those seeking to enhance their workstation configuration or optimize their DIT setup. It offers a diverse array of ports, along with an unoccupied M.2 slot that accommodates NVMe PCIe 3.0 x2 SSDs, enabling users to expand the dock's storage capabilities.

This dock is equipped with two Thunderbolt 3 ports, each capable of 40 Gb/s. One port can connect to a single device or daisy-chain up to five additional peripherals, while the other connects to the host system and delivers up to 87W for charging devices. Additional ports include a 10 Gb/s USB 3.1 Gen 2 Type-C port providing 5V / 3A power, two 5 Gb/s USB 3.1 Gen 1 Type-A ports with 5V / 1.2A power, a DisplayPort 1.2, a Gigabit Ethernet port, a UHS-II SD card reader with speeds reaching 270 MB/s, as well as 3.5mm jacks for headphones and microphones. Furthermore, this dock supports a single 5K display with resolutions up to 5120 x 2880 at 60 Hz, or dual 4K displays at 60 Hz.

General Features

• Connect all your peripherals and charge your Thunderbolt 3 (USB Type-C) enabled MacBook Pro with a single cable. Glyph's Thunderbolt 3 Dock has up to 40 Gb/s of throughput for data and video, and the ability to daisy-chain up to five additional devices.


• Glyph's Thunderbolt 3 Dock features an unoccupied M.2 slot designed for NVMe PCIe 3.0 x2 SSDs. Capable of achieving speeds of up to 1500 MB/s, this allows for an expansion of storage capacity while maintaining high performance levels. After installing a compatible SSD, it can be formatted for either Windows 10 or Mac OS X.
