Zoom B1 FOUR Guitar Multi-Effects Processor
Zoom B1 FOUR Guitar Multi-Effects Processor
STORE
54 Orchard Street
Ground Floor
New York NY 10002
United States
The Zoom B1 Four is a versatile multi-effects processor tailored for electric bass instruments. Presented in a user-friendly stompbox design, the B1 Four includes a diverse array of effects, amplifier simulations, and additional functionalities, including a 30-second looper and a chromatic tuner. With 68 integrated rhythm patterns, it allows for the incorporation of drum loops, enhancing the looping experience.
The pedal offers distortion, chorus, and additional effects, along with nine bass amplifier models that replicate classic combinations. Users can chain five effects in any sequence at any time and save them in one of the 50 user preset patches. Patches can be switched rapidly with a simple tap, allowing for seamless transitions in live or studio settings. Furthermore, global settings can be adjusted to maintain consistency across patches. The three-knob tone stack and overall output level remain unchanged while navigating through different sounds.
The pedal features 60 distinct effects, and users can also modify or incorporate additional effects via their computer. By connecting the pedal to a Mac or Windows device using a USB cable, one can enhance the effects through Zoom's Guitar Lab software.
The B1 Four features a 1/4" instrument input, a 3.5mm input for mobile devices and media players, and a combined amplifier/headphone output. It operates on four AA batteries, providing up to 18 hours of usage. Additionally, the unit can be powered using a dedicated ZOOM AD-16 AC adapter or via USB.
Additional Features
- Over 60 built-in effects
- 9 amp models for simulating classic rigs
- Up to 5 effects can be used simultaneously or chained together in any order
- Looper records up to 30 seconds (64 beats of CD-quality audio with seamless start and end times)
- ZOOM Guitar Lab software for creating, editing, and managing effects and patches
- 68 built-in rhythm patterns, which can be used in conjunction with the Looper
- 50 memory locations for storing user-created patches
- Auto Save function for automatic saving of all patch parameters
- Onboard chromatic tuner supports all standard guitar tunings including open and drop tunings
- Input jack accepts standard mono guitar cable
- Both active and passive instruments are supported
- Auxiliary input jack for connection of personal music players
- Output jack for connection to amp or headphones
- Runs on 4 AA batteries
- Alkaline battery life of 18 hours
- USB port for firmware updates, power, and connection to ZOOM Guitar Lab
Pedal |
|
|---|---|
| Simultaneous Effects | 5 Maximum |
| Patches | 50 User Patches |
| Sampling Frequency | 44.1 kHz |
| AD/DA Conversion | 24-Bit, 128x Oversampling |
| Signal Processing | 32-Bit, Internal |
| Display | 128 x 32 Dot Matrix LCD |
| Input | 1 x 1/4" TS Input, Phone Type 1 x 3.5 mm Auxiliary Input, Stereo, Phone Type |
| Input Level | 1/4" Instrument: -20 dBu 3.5 mm Auxiliary: -10 dBu |
| Input Impedance | 1/4" Instrument: 470 kOhms 3.5 mm Auxiliary: 1 kOhm |
| Output | 1 x 1/4" TRS Output (Combined Line and Headphone Jack) |
| Maximum Output Level | Line: +2 dBu Headphones: 17 mW + 17 mW |
| Output Impedance | Line: ≥10 kOhms Headphones: 32 Ohms Load |
| Signal to Noise Ratio | 120 dB |
| Noise Floor | -97 dBu |
| AC Adapter | 9 VDC, 500 mA, Center Negative (ZOOM AD-16) |
| Battery Power | 4 x AA Batteries |
| Battery Life | About 18 Hours, Continuous Operation with Using Alkaline Batteries |
| USB | MIDI: Micro-USB Type-B When Using a Cable Designed only for Power, other USB Functions Cannot be Used |
| Dimensions | 6.1 x 5.1 x 1.7" / 15.6 x 13.0 x 4.2 cm |
| Weight | 12 oz / 340 g |
